Description

This waterproof, brushless, steel-geared servo is perfect for Monster Truck and most Scaler and Crawler applications requiring a standard-sized servo. Precision steel gears, quick transit time, enormous torque, and waterproof to IP67 standards (operates for up to 30 minutes in water up to 3 feet deep).

Features:

Center aluminum with nylon composite top and bottom case

Operates directly on 7.4v without the need for an external BEC

Precision ball bearings

Specifications:

Torque @ 7.4v – 40.0kg/555 oz./in.

Speed @ 7.4v – 0.11 sec/60 deg

Torque @ 8.4v – 45.0kg/624.9 oz./in.

Speed @ 8.4v – 0.10 sec/60 deg

Weight: 79g / 3.1oz

Dimensions L x W x H (mm): 40.6 x 20.7 x 42

Technical Details

Operating Temperature: 14° – 122°F (-10° – 50°C)

Running Current (no load): 180mA @6.0V, 220mA @7.4V

Stall Current (at locked): 6000mA @6.0V, 7400mA @7.4V

Idle Current: 5mA @6.0V, 5mA @7.4V

Wire Length: 400 +/- 5mm

Output Gear Spline: 25 Tooth

Bearings: 2BB

Operating Travel: 100° (1000 → 2000 µ second)

Neutral Position: 1500 µ second

Pulse Width Range: 800 → 2200 µ second

Maximum Travel: Appx 130° (900 → 2100 µ second)

Refresh Rate: 333 Hz

Motor Type: Brushless
